AC Input:

200-240V / 4A

Frequency:

47-63 Hz

+5V:

17A

+3,3V:

18A

+5V & +3,3V combined:

110W

+12V 1:

38A/456W

+12V 2:

N/A

+12V 1 & +12V 2 combined:

N/A

+12V 3:

N/A

+12V 4:

N/A

+12V 3 & +12V 4 combined:

N/A

P.F.:

>0,9

-12V:

0,3A / 3,6W

+5VSB:

2,5A / 12,5W

Maximum Load:

500W

20+4PIN:

===400mm===[20+4PIN]

SATA:

===400mm===[Molex]===150mm===[SATA]===150mm===[SATA]

Molex/Sata:

===400mm===[SATA]===150mm===[Molex]===150mm===[Molex]

Molex/Sata:

===400mm===[SATA]===150mm===[SATA]

6+2PIN PCIe:

===400mm===[6+2PIN PCIe]

4PIN 12V :

===400mm===[4PIN 12V]
