ASUS LCD 24.1" PA24AC 1920x1200 16:10 ProArt IPS 100% sRGB HDR 400 DP over USB-C-VIDEO+60W DP HDMI USB3.0
Popis a parametry
ASUS LCD 24.1" PA24AC 1920x1200 16:10 ProArt IPS 100% sRGB HDR 400 DP over USB-C-VIDEO+60W DP HDMI USB3.0
https://www.asus.com/Monitors/PA24AC/
Display
Panel Size: Wide Screen 24.1"(61.13cm) 16:10
Color Saturation : 100%(sRGB)
Panel Type : IPS
True Resolution : 1920x1200
Display Viewing Area(HxV) : 518.4 x 324 mm
Brightness : 350 cd/? (Typical)/400 cd/? (Peak)
Contrast Ratio : 1000 :1 (Typical)/8000 :1 (HDR)
ASUS Smart Contrast Ratio (ASCR) : 100000000:1
Viewing Angle (CR?10) : 178°(H)/178°(V)
Response Time : 5ms (Gray to Gray)
Display Colors : 16.7M (real 8 bit)
Flicker free
LCD ZBD Warranty : Yes
Dynamically Local Dimming : Yes, 4 Zones
Video Feature
Trace Free Technology : Yes
SPLENDID Video Preset Modes : 8 Modes (sRGB Mode/Rec. 709 Mode/Scenery Mode/Standard Mode/User Mode 1/User Mode 2/Reading Mode/Darkroom Mode)
Color Temperature Selection : 4 Modes
Color Accuracy : ?E< 2
Gamma adjustment : Yes (Support Gamma 1.8/2.0/2.2/2.4/2.6 )
Color Adjustment : 6-axis adjustment(R,G,B,C,M,Y)
QuickFit (modes) : Yes (A4/B5/Alignment Grid/Ruler/Customization Modes)
Picture-in-Picture : Yes
Picture-by-Picture : Yes
Low Blue Light : Yes
HDCP support : Yes, 1.4 & 2.2
Adaptive-Sync supported :Yes
HDR (High Dynamic Range) Support :Yes
Audio Features
Stereo Speakers : 2W x 2 Stereo RMS
I/O Ports
Signal Input : HDMI(v2.0a) x2, DisplayPort 1.2, USB Type-C
Earphone jack : 3.5mm Mini-Jack
USB upstream : USB3.0 Type-C x1
USB downstream : USB3.0 Type-A x4
Signal Frequency
Digital Signal Frequency : 30 ~85 KHz (H) /48 ~70 Hz(V)
Power Consumption
Power On (Typical): < 21W*
Power Saving Mode : < 0.5W ; Power Off Mode : 0W (Hard Switch)
100-240V, 50/60Hz
Mechanical Design
Chassis Colors : Gray
Tilt : -5°~+23°
Swivel : -45°~+45°
Pivot : -90°~+90°
Height Adjustment : 0~110 mm
VESA Wall Mounting : 100x100mm
Frameless Design : Yes
Quick Release Stand Design : Yes
Security
Kensington lock
Dimensions
Phys. Dimension with Stand (WxHxD) : 532 x (378-488) x 202 mm
Phys. Dimension without Stand (WxHxD) : 532 x 349 x 55 mmBox Dimension (WxHxD) : 650 x 260 x 430 mm
Weight
Net Weight (Esti.) : 6.5 kg
Net Weight Without Stand (Esti.) : 4.28 kg
Gross Weight (Esti.) : 9 kg
Accessories
Power cord
DisplayPort cable
USB-C cable
USB-C to A cable
Quick start guide
HDMI cable
Warranty Card
Color pre-calibration report
Cable Clip
Compliance and Standards
Energy Star®, BSMI, CB, CCC, CE, CEL level , CU, ErP, FCC, ISO-9241-307, J-MOSS, KCC, Mac Compliance, PSE, RoHS, TCO7.0, UkrSEPRO, UL/cUL, VCCI, WEEE, WHQL (Windows 10, Windows 8.1, Windows 7), MEPS, TUV Flicker-free , KC , eStandby, TUV Low Blue Light, Vietnam MEPS, ICES-3, RCM, VESA DisplayHDR 400
Note
*HDCP2.2 for HDMI and DisplayPort ports
*Adaptive-Sync for HDMI and DisplayPort ports
*HDR-10 by HDMI / DisplayPort ports. HDR performance requires compatible monitors, streaming devices, video graphic cards, OS and playback software for PC devices or media players which all support HDR function.
.
Display
Panel Size: Wide Screen 24.1"(61.13cm) 16:10
Color Saturation : 100%(sRGB)
Panel Type : IPS
True Resolution : 1920x1200
Display Viewing Area(HxV) : 518.4 x 324 mm
Brightness : 350 cd/? (Typical)/400 cd/? (Peak)
Contrast Ratio : 1000 :1 (Typical)/8000 :1 (HDR)
ASUS Smart Contrast Ratio (ASCR) : 100000000:1
Viewing Angle (CR?10) : 178°(H)/178°(V)
Response Time : 5ms (Gray to Gray)
Display Colors : 16.7M (real 8 bit)
Flicker free
LCD ZBD Warranty : Yes
Dynamically Local Dimming : Yes, 4 Zones
Video Feature
Trace Free Technology : Yes
SPLENDID Video Preset Modes : 8 Modes (sRGB Mode/Rec. 709 Mode/Scenery Mode/Standard Mode/User Mode 1/User Mode 2/Reading Mode/Darkroom Mode)
Color Temperature Selection : 4 Modes
Color Accuracy : ?E< 2
Gamma adjustment : Yes (Support Gamma 1.8/2.0/2.2/2.4/2.6 )
Color Adjustment : 6-axis adjustment(R,G,B,C,M,Y)
QuickFit (modes) : Yes (A4/B5/Alignment Grid/Ruler/Customization Modes)
Picture-in-Picture : Yes
Picture-by-Picture : Yes
Low Blue Light : Yes
HDCP support : Yes, 1.4 & 2.2
Adaptive-Sync supported :Yes
HDR (High Dynamic Range) Support :Yes
Audio Features
Stereo Speakers : 2W x 2 Stereo RMS
I/O Ports
Signal Input : HDMI(v2.0a) x2, DisplayPort 1.2, USB Type-C
Earphone jack : 3.5mm Mini-Jack
USB upstream : USB3.0 Type-C x1
USB downstream : USB3.0 Type-A x4
Signal Frequency
Digital Signal Frequency : 30 ~85 KHz (H) /48 ~70 Hz(V)
Power Consumption
Power On (Typical): < 21W*
Power Saving Mode : < 0.5W ; Power Off Mode : 0W (Hard Switch)
100-240V, 50/60Hz
Mechanical Design
Chassis Colors : Gray
Tilt : -5°~+23°
Swivel : -45°~+45°
Pivot : -90°~+90°
Height Adjustment : 0~110 mm
VESA Wall Mounting : 100x100mm
Frameless Design : Yes
Quick Release Stand Design : Yes
Security
Kensington lock
Dimensions
Phys. Dimension with Stand (WxHxD) : 532 x (378-488) x 202 mm
Phys. Dimension without Stand (WxHxD) : 532 x 349 x 55 mmBox Dimension (WxHxD) : 650 x 260 x 430 mm
Weight
Net Weight (Esti.) : 6.5 kg
Net Weight Without Stand (Esti.) : 4.28 kg
Gross Weight (Esti.) : 9 kg
Accessories
Power cord
DisplayPort cable
USB-C cable
USB-C to A cable
Quick start guide
HDMI cable
Warranty Card
Color pre-calibration report
Cable Clip
Compliance and Standards
Energy Star®, BSMI, CB, CCC, CE, CEL level , CU, ErP, FCC, ISO-9241-307, J-MOSS, KCC, Mac Compliance, PSE, RoHS, TCO7.0, UkrSEPRO, UL/cUL, VCCI, WEEE, WHQL (Windows 10, Windows 8.1, Windows 7), MEPS, TUV Flicker-free , KC , eStandby, TUV Low Blue Light, Vietnam MEPS, ICES-3, RCM, VESA DisplayHDR 400
Note
*HDCP2.2 for HDMI and DisplayPort ports
*Adaptive-Sync for HDMI and DisplayPort ports
*HDR-10 by HDMI / DisplayPort ports. HDR performance requires compatible monitors, streaming devices, video graphic cards, OS and playback software for PC devices or media players which all support HDR function.
.
ParametryPorovnání
Formát obrazovky
16:10
Rozlišení displeje
1920x1200
Povrchová úprava displeje
Matný
Rozhraní
DisplayPort
Rozhraní
HDMI
Rozhraní
3.5mm Jack
Výbava
Reproduktory
Výbava
Pivot
Výbava
VESA montáž
Výbava
Dokování NTB
Výbava
Redukce blikání (flicker-free)
Výbava
Redukce modrého světla
Typ panelu
IPS
Barevná hloubka (bit)
8
Úhlopříčka displeje (")
24,1
Kontrast:1
1000
Doba odezvy (ms)
5
Hmotnost (kg)
9
Jas (cd/m2)
350
